Input
TP04: PT100Ω ; TD04: PT1000Ω class A
PT100Ω sensor current
< 0.8mA
Output
4～20mA DC (2-wire)
Accuracy
± 0.5 % of F.S.
Overload Resistance
≦ (supply voltage - 8 V) / 0.02A Ω
Output calibration(ZERO & SPAN)adjustment range
ZERO adjustment range:±10 %
SPAN adjustment range:TP04: ±10 %/ TD04:computer calibration
Power Supply
10∼30VDC
Protection Degree
TP04:IP65
TD04:IP67
