Construction According EN 50014 and EN 50019
Ex execution II 2G Eex e II T6
Certificate KEMA02ATEX2237 X
Suitable for zone 1 and 2
Ingress protection IP65 / IEC529
Ambient temp. range -40°C...+80°C
Connection head DAN. Cable entry M20 x 1.5 female
Material Cast aluminium enamel coated
Mounting In the cover of the head
Transmitter
Model Select from our standard range or specify your standardized brand
Range and output data To specify
Head mounted Standard mounted on insert, replaces the terminal block
Alternative mounting Mounted in the cover of the head
Sensing element Replaceable, springloaded
Type Mineral insulated, diameter 6mm
Calibration K, T, J, E, N, R, S, B, U or L
For duplex KK, TT, JJ, EE, NN, RR, SS, BB, UU or LL
Accuracy According IEC 584
Extension
Type Nipple - union - nipple
Material Stainless Steel 316
Connection 1/2" NPT male thread
Length "X" 150 mm standard, other length possible
