Input
PT 100Ω (3-wire)
Accuracy
± 0.1 % of F.S.
Output
4 ~ 20 mA DC (2-wire)
Cable Resistance
≦ 50 Ω (3 wires with the same resistance)
Overload Resistance
≦ (supply voltage - 8 V) / 0.02A Ω
PT100Ω signal disconnection protection & output
>23mA
Power Supply
10 ~ 30 VDC
Protection Degree
Housing: IP30 ; Terminal: IP10
